DC 24V Sliding Gate Opener /Sliding Gate Motor 800kg - SD

DC 24V Sliding Gate Opener /Sliding Gate Motor 800kg, Compact & Fashionable & Quality Reliable, Build in control board - details see: https://www.buildingsupplieshub.com/dc-24v-sliding-gate-opener-sliding-gate-motor-800kg-10049201
Type: Gate OperatorsPlace of Origin: Guangdong China (Mainland)Brand Name: AhouseModel Number: SD
Color: Silvery& GreeCertification: CE&IP57Own Patent: Hall sensorOperating Voltage: DC 24V
Electronic Controller: Microcontroller BasedSafety Detection: Over Current DetectionSafety Barrier: Infrared Beam Sensor (Optional)Infrared Beam Sensor (Optional): 600~800 kg
Motor speed: 1800 rpmFrequency: 433.92 MHz
DC 24V Sliding Gate Opener /Sliding Gate Motor 800kg
contact supplier for DC 24V Sliding Gate Opener /Sliding Gate Motor 800kg


DC 24V sliding gate opener/Sliding Gate Motor 800KG

Features:

  • The gate operator contains build-in control board and transfomer
  • Electronic process limitation and memory cycles by hall
  • Intelligent digital adjustment supplied with gate operator
  • Safety low voltage in the operator is 24V DC
  • Gate Unit has “moving-anywhere” function
  • Gate Unit has a solar input

Main specification & technical parameters of Sliding Gate Operator:

  • Motor: 24V DC 120~140W
  • Output speed: 40 rpm
  • Limit: Electronic process limitation
  • Max. Gate Weight: 800kg
  • Motor speed: 1800 rpm
  • Gate Max moving speed: 17m/min
  • Remote control distance: >30 m
  • Frequency: 433.92 M
  • Noise: <68 dB
  • Environmental temperature: -15°C ~ +55°C
  • Storage battery: 12V 7 Ah

Outer packing dimensions: 40*30*18.5 cm

Optional Accessaries:

Metal Gear Rack & Nylon Gear Rack are optional, both are 1m/pc

Photo beam sensor

Keypad systems

Warning light

Gear rack

Power SupplyAC110v~240v
Operating VoltageDC 24V
Electronic ControllerMicrocontroller Based
Safety DetectionOver Current Detection
Safety BarrierInfrared Beam Sensor (Optional)
Max. Gate Weight600~800 kg
Motor speed1800 rpm
Gate moving speed13m/min
Operating distance≥50m
Frequency433.92 MHz
Remote control modeClose/ Open/ Stop/ Half Open
Auto close time0~99 sec (Adjustable)
Noise≤65dB
Product actual size29*23*15 cm
Packing size40*30*18.5 cm
Environmental Temperature-15°C to +55°C

Lohas Ahouse

Packaging Detail:one carton for one set Packing size:40x30x18.5(cm)
Delivery Detail:within 1 ~ 15 days
